Kia EV6: Components and Components Location

Component

Kia EV6. Components and Components Location

1. Rear Bumper Beam Assembly
2. Rear Bumper Harness
3. Ultrasonic Sensor (PDW-R)
4. Rear Corner Radar
5. Rear Bumper Side Cover
6. Rear Bumper Reflector
7. Back-up Lamp
8. Rear Side Under Cover Mounting Bracket Assembly
9. Rear Center Under Cover Mounting Bracket Assembly
10. Rear Bumper Under Cover
11. Rear Bumper Skid Plate
12. Rear Hook Cap
13. Rear Bumper Side Bracket
14. Rear Bumper Cover
